產品簡介：ACPhotonics的粗波分復用（CWDM）利用薄膜涂覆技術和非焊劑金屬接合微光學包裝專有設計。它提供了低插入損耗，高信道隔離，寬的通帶，低溫敏感性和環氧自由光路。性能參數ParameterSpecificationsAddDropOperatingWavelengthFullBand(FB):1270nmto1610nm;Standard:1270nmto1350nmor1430nm
產品簡介：
ACPhotonics的粗波分復用（CWDM）利用薄膜涂覆技術和非焊劑金屬接合微光學包裝專有設計。它提供了低插入損耗，高信道隔離，寬的通帶，低溫敏感性和環氧自由光路。
性能參數
|
Parameter |
Specifications |
||
|
Add |
Drop |
||
|
Operating Wavelength |
Full Band (FB): 1270nm to 1610nm; |
||
|
Center Wavelength |
1270nm, 1290nm, …., 1610nm or 1271nm, 1291nm, ….1611nm |
||
|
Center Wavelength Accuracy |
± 0.5nm |
||
|
Channel Spacing |
20GHz |
||
|
Channel Passband (@-0.5dB bandwidth) |
≥ 13nm |
||
|
Insertion Loss |
Add / Drop Ch. |
≤ 0.6dB |
≤ 0.6dB |
|
Express Ch. |
≤ 0.6dB |
≤ 0.6dB |
|
|
Add / Drop Channel Ripple |
≤ 0.3dB |
≤ 0.3dB |
|
|
Isolation@Add/Drop Channel |
Adjacent |
N/A |
≥ 30dB |
|
Non-adjacent |
N/A |
≥ 40dB |
|
|
Express Channel Isolation |
≥ 25dB |
||
|
Insertion Loss Temperature Sensitivity |
≤ 0.003dB/°C |
||
|
Wavelength Temperature Shifting |
≤ 0.002nm/°C |
||
|
Polarization Dependent Loss |
≤ 0.10dB |
||
|
Polarization Mode Dispersion |
≤ 0.10ps |
||
|
Directivity |
≥ 50dB |
||
|
Return Loss |
≥ 45dB |
||
|
Optical Power |
300mW |
||
|
Operating Temperature |
0 to +70°C |
||
|
Storage Temperature |
-40 to +85°C |
||
|
Package Dimensions |
L80.0nm x W50.0nm x H6.0nm |
||
